LIAN LI EDGE 750W GOLD L SHAPE FULLY MODULAR [ BLACK ]
Description
Specifications
| Model | EG0750G |
| Dimensions | 182mm (D) x 86mm (W) x 150mm (H) |
| Design | Fully modular |
| Color | Black |
| Material | Steel |
| Form Factor | ATX 3.1 |
| Certification | 80 PLUS GOLD / Cybenetics GOLD / PPLP GOLD |
| Max DC Output | 750W |
| +3.3V & +5V Combined | 120W |
| +12V Combined | 744W |
| Input Voltage | 100-240Vac |
| Frequency / Current | 9-4.5A 50-60Hz |
| PFC | Active PFC (PF > 0.90) |
| Efficiency (Max) | 90.52% |
| Protection | OCP / OVP / OTP / OPP / SCP / UVP |
| Fan Type | 120mm FDB |
| Fan Speed | 2000RPM |
| Noise Level | 30.9dBA |
| Connectors | 1 x 24/20-Pin motherboard connector (620mm) x1pcs 1 x 8 pin CPU/ATX 12V connector (750mm) x1pcs 1 x 4+4 Pin CPU connector (750mm) x1pcs 1 x 6+2 Pin GPU connector (650mm+100mm) x1pcs 1 x SATA connector (300mm-15mm-15mm-15mm) x1pcs 1 x SATA-Y connector (375mm-150mm-150mm) x 1pcs 1 x SATA connector (400mm-150mm-150mm-150mm) x1pcs 4 x 4-Pin Peripheral connector (500mm-150mm-150mm-150mm) x1pcs 1 x 12V – 2X6 450W connector (650mm) x1pcs 2 x 6+2 Pin GPU connector (650mm) x2pcs |
