LIAN LI UNI FAN TL 120-1 WHITE
Description
SPECIFICATIONS
| MODEL NAME | UNI FAN TL 120 | UNI FAN TL 140 | ||||
|---|---|---|---|---|---|---|
| MODEL NO. | 12TL3B | 12TL3W | 12TL1B | 12TL1W | 14TL1B | 14TL1W |
| COLOR | BLACK | WHITE | BLACK | WHITE | BLACK | WHITE |
| NUMBER OF FANS | 3 | 3 | 1 | 1 | 1 | 1 |
| CONTROLLER | Yes | No | NO | |||
| CONNECTOR TYPE | UNI FAN Controller Cable x 1 (P-7P) Extension Cable x 1 (P-P) Power Adapter Cable x 1 (P-SA) | UNI FAN Controller Cable x 1 (P-7P) Extension Cable x 1 (P-P) | UNI FAN Controller Cable x 1 (P-7P) Extension Cable x 1 (P-P) | |||
| FAN DIMENSION | 124 x 120 x 28 mm | 144 X 140 X 28 (mm) | ||||
| FAN SPEED | 0, 200~2600 RPM | 0, 200~1800 RPM | ||||
| MAX. AIR PRESSURE | 3.97 mmH2O (Maximum) | 2.34 mmH2O (Maximum) | ||||
| MAX. AIRFLOW | 90.1 CFM (Maximum) | 103.9 CFM (Maximum) | ||||
| ACOUSTIC NOISE | 33 dB(A) Max | 29 dB(A) Max | ||||
| INPUT POWER | 5.8W | 4.6W | ||||
| MATERIAL | PA66 / LCP | |||||
| RATED VOLTAGE | DC 12V (FAN) & 5V (LED) | |||||
| BEARING TYPE | Fluid Dynamic Bearing (FDB) | |||||
| OPERATE VOLTAGE | DC12V & 5V | |||||
| WARRANTY | 3 years | |||||
| MODEL NAME | UNI FAN TL 120 REVERSE BLADE | UNI FAN TL 140 REVERSE BLADE | ||||
|---|---|---|---|---|---|---|
| MODEL NO. | 12RTL3B | 12RTL3W | 12RTL1B | 12RTL1W | 14RTL1B | 14RTL1W |
| COLOR | BLACK | WHITE | BLACK | WHITE | BLACK | WHITE |
| NUMBER OF FANS | 3 | 3 | 1 | 1 | 1 | 1 |
| CONTROLLER | Yes | No | NO | |||
| CONNECTOR TYPE | UNI FAN Controller Cable x 1 (P-7P) Extension Cable x 1 (P-P) Power Adapter Cable x 1 (P-SA) | UNI FAN Controller Cable x 1 (P-7P) Extension Cable x 1 (P-P) | UNI FAN Controller Cable x 1 (P-7P) Extension Cable x 1 (P-P) | |||
| FAN DIMENSION | 124 x 120 x 28 mm | 144 X 140 X 28 (mm) | ||||
| FAN SPEED | 0, 200~2300 RPM | 0, 200~1800 RPM | ||||
| MAX. AIR PRESSURE | 2.66 mmH2O (Maximum) | 2.27 mmH2O (Maximum) | ||||
| MAX. AIRFLOW | 83.4 CFM (Maximum) | 101.6 CFM (Maximum) | ||||
| ACOUSTIC NOISE | 34 dB(A) Max | 31 dB(A) Max | ||||
| INPUT POWER | 4.5W | 4.6W | ||||
| MATERIAL | PA66 / LCP | |||||
| RATED VOLTAGE | DC 12V (FAN) & 5V (LED) | |||||
| BEARING TYPE | Fluid Dynamic Bearing (FDB) | |||||
| OPERATE VOLTAGE | DC12V & 5V | |||||
